Dell 24-Outlets PDU
Dell 24-Outlets PDU - Basic - NEMA L6-30P - 20 x IEC 60320 C13, 4 x IEC 60320 C19 - 230 V AC - 10 ft Cord Length - 0U - Horizontal/Vertical/Toolless - Rack-mountable - Rack
GPC-payable · TAA-compliant configuration on request · usually back within one business day.
- Product Type
- PDU
- Phase
- Single Phase/Three Phase
- Receptacle Type
- IEC 60320 C13
- Receptacle Type
- IEC 60320 C19
- UL Listed
- Yes
- PDU Type
- Basic
- Mounting Orientation
- Horizontal/Vertical/Toolless
- Power Rating (VA)
- 4992 VA
Overview
Dell 24-Outlets PDU - Basic - NEMA L6-30P - 20 x IEC 60320 C13, 4 x IEC 60320 C19 - 230 V AC - 10 ft Cord Length - 0U - Horizontal/Vertical/Toolless - Rack-mountable - Rack (part number A7284203) is supplied by Uniqcli, an authorized Dell Technologies partner, in the Dell PDUs category. Additional Warranty Information: 2 years repair or replace.
Power Distribution The growing complexity of IT environments, from wiring closets and server rooms to data centers of all sizes, has increased the need for reliable power distribution to the rack level. Eliminating power management issues is essential for IT and Facilities managers to maintain system availability of increasing higher density equipment. Power Distribution Units are an essential element in managing power capacity and functionality for critical network, server and data center equipment. APC provides a wide array of power distribution solutions for your IT environment. APCs standardized PDUs are designed to increase the manageability and efficiency of your data center. Power Distribution solutions provide real-time remote load monitoring of connected equipment and individual outlet power control for remote power recycling, manage power-up or power-down sequencing of equipment. IT and Data Center Managers rely on APC PDU alarms to warn of potential power overloads before critical IT failures occur. Reliable rack power distribution | Our best value rack PDU APC Basic Rack PDUs provide reliable rack power distribution via a single input with multiple output receptacles and distributes power from low amperage single phase circuits to higher-power 3-phase solutions. Basic Rack PDU Features & Benefits | Agility Rack-Mountable Includes horizontal, vertical, and toolless-mount varieties. Puts power where it is needed most - in the racks near the equipment. Single input power source Supply power from one branch whip to multiple pieces of equipment, conveniently powering rack-mount equipment. Saves time and money during installation by using one branch whip and standard connections. Wide range of input and output connections Product family includes a variety of input and output connections to distribute 120V, 208V, or 230V power to multiple outlets. Having a variety of inputs and outputs allow users to adapt to varying power requirements. APC offers units that bring up to 14.4kW using a single branch whip. Total Cost of Ownership Low Cost Power Distribution Provides a number of outlets to bring power to rack equipment at an affordable price.
• PDU allows power to be more efficiently distributed and controlled • Basic PDU is the space-saving and cost-effective way to deliver power • IEC 60320 C13 receptacle type to ensure maximum usability and reliable power output • With Side mount your PDUs in proper angle for efficient working • Single phase/three phase PDU for reliable performance with maximum productivity
Key specifications: Additional Warranty Information: 2 years repair or replace · Limited Warranty: 2 Year Year · Phase: Single Phase/Three Phase · Receptacle Type: IEC 60320 C13, IEC 60320 C19 · PDU Type: Basic · Receptacle Detail: 20 x IEC 60320 C13, 4 x IEC 60320 C19 · Plug/Connector Type: NEMA L6-30P · Environmentally Friendly: Yes.
GPC-payable and available on GSA and government contract vehicles. Ask us about TAA-compliant configurations, current pricing, stock, and lead time.
Key features
- PDU allows power to be more efficiently distributed and controlled
- Basic PDU is the space-saving and cost-effective way to deliver power
- IEC 60320 C13 receptacle type to ensure maximum usability and reliable power output
- With Side mount your PDUs in proper angle for efficient working
- Single phase/three phase PDU for reliable performance with maximum productivity
- NEMA L6-30P plug/connector type for better, dependable connectivity and desired power output
- 230 V AC input voltage for better reliance and maximum dependability
- 200 V AC output voltage for better reliance and maximum usability
Tech specs
Power Description
- Power Rating (VA)
- 4992 VA W
- Input Voltage Range
- 208 V AC - 240 V AC
- Input Current
- 30 A A
- Input Voltage
- 230 V AC
- Output Voltage
- 200 V AC, 208 V AC
Physical Characteristics
- Mounting Orientation
- Horizontal/Vertical/Toolless
- Product Color
- Black
- Color Family
- Black
- Placement
- Side
- Cord Length
- 10 ft mm
- Height
- 63.7" mm
- Width
- 2.2" mm
- Depth
- 1.7" mm
- Rack Height
- 0U
- Form Factor
- Rack
- Mount Type
- Rack-mountable
- Weight (Approximate)
- 12.28 lb g
General Information
- Product Type
- PDU
- Packaged Quantity
- 1 Each
Technical Information
- Phase
- Single Phase/Three Phase
- Receptacle Type
- IEC 60320 C13, IEC 60320 C19
- PDU Type
- Basic
- Receptacle Detail
- 20 x IEC 60320 C13, 4 x IEC 60320 C19
- Plug/Connector Type
- NEMA L6-30P
Warranty
- Additional Warranty Information
- 2 years repair or replace
- Limited Warranty
- 2 Year Year
Miscellaneous
- Environmentally Friendly
- Yes
- UL Listed
- Yes
- Environmental Compliance
- Registration, Evaluation, Authorization and Restriction of Chemicals (REACH), Waste Electrical and Electronic Equipment Directive (WEEE), Restriction of Hazardous Substances (RoHS)
- Country of Origin
- United States
- Application/Usage
- IT Equipment, Server/Network Rack, Data Center
- Package Contents
- 24-Outlets PDU Installation Guide Rack Mounting Brackets Toolless Mounting Kit
