Representative imageDell PowerEdge R570 2U Rack-mountable Server
Dell PowerEdge R570 2U Rack-mountable Server - 1 x Intel Xeon 6 6511P 2.30 GHz - 128 GB RAM - 480 GB SSD - 12Gb/s SAS, Serial ATA/600, NVMe Controller - Intel Chip - 1 Processor Support - 4 TB RAM Support - DDR5 SDRAM - 10 Gigabit Ethernet - 12 x Total Bay(s) - 12 x LFF Bay(s) - Hot Swappable Bays - 2 x 1100 W - Redundant Power Supply
GPC-payable · TAA-compliant configuration on request · usually back within one business day.
- Product Type
- Server
- Processor Core
- Hexadeca-core (16 Core)
- Processor Manufacturer
- Intel
- Redundant Power Supply
- Yes
- Number of Processors Supported
- 1
- Number of Processors Installed
- 1
- RAID Supported
- No
- Ethernet Technology
- 10 Gigabit Ethernet
Overview
Dell PowerEdge R570 2U Rack-mountable Server - 1 x Intel Xeon 6 6511P 2.30 GHz - 128 GB RAM - 480 GB SSD - 12Gb/s SAS, Serial ATA/600, NVMe Controller - Intel Chip - 1 Processor Support - 4 TB RAM Support - DDR5 SDRAM - 10 Gigabit Ethernet - 12 x Total Bay(s) - 12 x LFF Bay(s) - Hot Swappable Bays - 2 x 1100 W - Redundant Power Supply (part number R570271_6511P432) is supplied by Uniqcli, an authorized Dell Technologies partner, in the Dell Servers category. Cache: 72 MB Byte.
Unprecedented Single-Socket Server with Optimized Power and Balanced Performance | Drive value and efficiencies in large datacenters The Dell PowerEdge R570 is a powerful 2U, single-socket rack server designed to deliver high performance while maintaining exceptional energy efficiency. Its advanced design helps drive cost savings and improve data center productivity. With more cores in a single socket, the R570 delivers superior performance in a compact footprint, all while minimizing power consumption. This makes it perfect for workloads like virtualization, medium-density VMs, scale-out databases, VDI, and software-defined storage. Purpose-built for enterprise and scalable infrastructures, the PowerEdge R570 seamlessly integrates into current environments. Designed for diverse performance and expandability needs, it is powered by an Intel® Xeon® 6 processor and offers advanced GPU support. This boosts computational capabilities and accelerates inferencing power, making it suitable for demanding business applications. The server is available in rear I/O hot aisle and front I/O cold aisle configurations. The front I/O cold aisle option enhances serviceability, reduces maintenance downtime, and improves overall system reliability. Additionally, Dell's Smart Power and Cooling Technology will enable your IT and datacenter requirements with air-cooled solution.. Cyber Resilient Architecture for Zero Trust IT environment & operations Security is integrated into every phase of the PowerEdge lifecycle, including protected supply chain and factory-to-site integrity assurance. The Silicon-based root of trust anchors end-to-end boot resilience while Multi-Factor Authentication (MFA) and role-based access controls safeguard trusted operations. Increase efficiency and accelerate operations with autonomous collaboration The Dell OpenManage systems management portfolio tames the complexity of managing and securing IT infrastructure. Using Dell Technologies' intuitive end-to-end tools, IT can deliver a secure, integrated experience by reducing process and information silos in order to focus on growing the business. The Dell OpenManage portfolio is the key to your innovation engine, unlocking the tools and automation that help you scale, manage, and protect your technology environment. Sustainability From recycled materials in our products and packaging, to thoughtful, innovative options for energy efficiency, the PowerEdge portfolio is designed to make, deliver, and recycle products to help reduce the carbon footprint and lower your operation costs. We even make it easy to retire legacy systems responsibly with Dell Technologies.
• 1 processors supported for optimal performance and maximum reliability in mission-critical server environments • 128 GB memory supports running multiple apps and intensive tasks lag-free, ideal for creative and analytical workflows • 480 GB SSD offers ample space for important documents, files, and critical data, ensuring reliability and quick access • 2 x 1100 W power supply unit (PSU) included for dependable performance and redundancy in enterprise setups • Xeon 6 processor works with modern DDR5 memory technologies, helping data move quickly so apps stay responsive during sustained activity
Key specifications: Cache: 72 MB Byte · Processor Core: Hexadeca-core (16 Core) · Processor Manufacturer: Intel · Number of Processors Supported: 1 · Number of Processors Installed: 1 · Processor Model: 6511P · Processor Speed: 2.30 GHz Hz · Processor Type: Xeon 6.
GPC-payable and available on GSA and government contract vehicles. Ask us about TAA-compliant configurations, current pricing, stock, and lead time.
Tech specs
Processor
- Cache
- 72 MB Byte
- Processor Core
- Hexadeca-core (16 Core)
- Processor Manufacturer
- Intel
- Number of Processors Supported
- 1
- Number of Processors Installed
- 1
- Processor Model
- 6511P
- Processor Speed
- 2.30 GHz Hz
- Processor Type
- Xeon 6
Chipset
- Chipset Manufacturer
- Intel
Power Description
- Number of Power Supplies Supported
- 2
- Number of Power Supplies Installed
- 2
- Redundant Power Supply
- Yes
- Hot Swappable Power Supply
- Yes
- Maximum Power Supply Wattage
- 1100 W W
- Plug/Connector Type
- NEMA 5-15P to C13
- Input Voltage
- 120 V AC V AC, 230 V AC V AC
Controllers
- RAID Supported
- No
- Controller Model
- PERC H965i
- Controller Type
- 12Gb/s SAS, Serial ATA/600, NVMe
Network & Communication
- Ethernet Technology
- 10 Gigabit Ethernet
I/O Expansions
- Number of Total Expansion Bays
- 12
- Number of 3.5" Bays
- 12
- Total Number of Expansion Slots
- 5
- Hot Swappable Bays
- Yes
- Number of LFF Bays
- 12
- PCI Express Details
- 3× PCIe Gen5 x16 (Full Height), 2× OCP 3.0 x16
- Riser Card
- Riser Config 10, Rear Full Height 1x16 Onboard OCP, 1x16 FLOP OCP, 3x16 FH (Gen5)
Memory
- Number of Occupied Memory Slots
- 4
- Total Number of Memory Slots
- 16
- Memory Technology
- DDR5 SDRAM
- Error Checking
- ECC
- Maximum Memory Supported
- 4 TB Byte
- Signal Processing
- Registered (Buffered)
- Standard Memory
- 128 GB Byte
Physical Characteristics
- Height
- 3.4" mm
- Width
- 19" mm
- Depth
- 31.6" mm
- Rack Height
- 2U
- Form Factor
- Rack-mountable
Operating System
- Operating System Supported
- Hyper-V, Windows Server, Red Hat Enterprise Linux, SuSE Linux Enterprise Server, Ubuntu Server LTS
Miscellaneous
- Security Features
- Cryptographically signed firmware Data at Rest Encryption (SEDs with local or external key mgmt) Secure Boot Secured Component Verification (Hardware integrity check) Secure Erase Silicon Root of Trust System Lockdown TPM 2.0 FIPS, CC-TCG certified Chassis Intrusion Detection
- Package Contents
- PowerEdge R570 Server NEMA 5-15P to C13 Wall Plug (125 Volt, 15 AMP, 10 Feet 3m) 2U Combo Drop-In/Stab-In Rails with Cable Management Arm
Interfaces/Ports
- VGA
- Yes
- Number of Network (RJ-45) Ports
- 2
- Network (RJ-45)
- Yes
- Remote Management
- Yes
- Total Number of USB Ports
- 4
- Number of USB 2.0 Ports
- 2
- Number of USB 3.1 Type-A Ports
- 2
- Remote Management Controller
- iDRAC10, Enterprise 17G
General Information
- Product Type
- Server
- Product Model
- R570
Storage
- Solid State Drive Interface
- Serial ATA/600
- Total Solid State Drive Capacity
- 480 GB Byte
